One of the most capable pick-up trucks on the market and clearly the best sold in the US is the popular Ford F-150. The car underwent major changes when the new generation was introduced, and along with the new aluminium frame, the car also received some nasty shock absorbers, that Ford says are the toughest in the industry.

The new absorbers can be found only on the Raptor version of the F-150 and were developed together with Fox specialists.

The new 3.0-inch FOX shock adds a base valve piston that enables lower gas pressure, resulting in a more comfortable-riding truck on the road. The internal bypass in the front and rear shocks has nine distinct zones that progressively manage shock forces, allowing for smooth on-road trips along with hard-hitting off-road driving. The final zones act like hydraulic bump stops to send fluid through the top of the piston while the shock is fully compressed, preventing Raptor from bottoming out.


F-150 Raptor’s front and rear FOX shocks have grown from 2.5 inches to 3.0 inches in diameter for improved performance – offering 44 percent more volume for increased heat dissipation and fade resistance. Nearly two inches more suspension travel over the previous truck’s 11.2-inch front and 12.0-inch rear bring 2017 F-150 Raptor shocks to 13.0 inches at the front and 13.9 inches at the rear – roughly a 15 percent increase in overall suspension travel.

With a larger-diameter outer body and internal piston, the new FOX shocks allow Raptor to handle harder impacts while reducing harshness to the driver.
